Product Feature
● Lightweight Efficiency: The servo is lightweight (85g) and efficient, ideal for weight-sensitive applications.
● Compact Size: Its compact dimensions (54.252039.35mm) allow for installation in tight spaces.
● Extended Lifespan: A brushless motor design offers an extended lifespan with less wear than brushed servos.
● Universal Application: This versatile servo is compatible with a broad range of RC systems for diverse applications.
● Superior Gear Train: Equipped with a high-precision gear train, it provides smooth, accurate control with minimal backlash.
● Quality Assurance: Rigorous testing ensures the servo’s quality, performance, and reliability for critical applications.
The full aluminum case brushless servo CYS-BLS5840, a testament to engineering excellence in a compact package. Its brushless motor technology is the heart of its reliability, offering smoother operation and faster response times than traditional brushed servos. This translates to increased efficiency and a significant reduction in wear, granting this servo a longer life span and consistent performance. Moreover, its lightweight design does not hinder its power, as it delivers the torque and speed necessary to handle demanding tasks with ease.
| Operation Voltage(Rated) | DC7.4V |
| Operation Voltage Range | DC6.0V-8.4V |
| Rated Torque | 15kgf.cm@7.4V |
| Stalling torque | 45kgf.cm@7.4V |
| No-load Speed | 0.075sec/60°@7.4V |
| Rated Speed | 0.08sec/60°@7.4V |
| Travel Angle |
±50°when 1000us-2000us
|
| Travel Angle | ±100°when 500us-2500us |
| Operating Temperature Range | -20℃......+65C |
| Case Dimensions | 40*20*39.3MM |
| Weight | 85g±1g |
